21.52MM  SGP Clear Tempered Laminated Glass, 10 10 1.52 SGP Sentry T Laminated Glass, bomb blasting resistance safety glass

21.52MM SGP Clear Tempered Laminated Glass, 10 10 1.52 SGP Sentry T Laminated Glass, bomb blasting resistance safety glass

  • Glass type: SGP Sentry Laminated Glass
  • Other name: SGP film laminated glass / Hurricane proof glass/ SGP Glass
  • Composition: tempered glass + SGP Sentry Film + tempered glass + SGP Sentry Film + tempered glass
  • Shape: flat and curved
  • Glass color: clear glass, acid etched glass, printed glass, blue, green, grey, bronze
  • Glass Thickness: 4mm 5mm 6mm 8mm 10mm 12mm 15mm 19mm
  • PVB color: clear, white, milky white,or other pantone colors
  • PVB Thickness: 0.76mm,1.52mm,2.28mm
  • Glass size: Maximum 8000 mm
  • Interlayer material: SGP
  • Package: exportation wood crates
  • Delivery: 7-15 days
  • Container size: LCL, 20'GP, 20'OT
Sun Global Glass Factory is composed of a tough plastic interlayer composite that is laminated between two layers of tempered glass. It extends the performance of laminated glass beyond current technologies as the interlayer offers five times the tear strength and 100 times the rigidity of the more conventional PVB interlayer. SGP satisfies consumers’ requests for break-resistant windows by providing added security , even in accidents. The adhesive interlayer increases occupant safety and reduces the risk of lacerations from flying pieces of broken glass.


Specification:

1.Glass Substrate Options: ultra clear float glass, clear float glass, tinted glass, reflective glass, silkscreen glass, Low-E glass, Frosted glass, etc.
2.SGP Sentry film thickness: 0.76mm /1.52mm /2.28mm /3.04mm (QTY 4*0.76mm)... 0.76mm or multiples of 0.76mm
3.SGP brand:  Du Pont or Saflex SOLUTIA
4.Max length: 6000mm, can be bespoken
5.Max width: 2500mm, can be customized
6.Both flat laminated glass and curved laminated glass are available


Advantages compared to PVB film:

1.Super highly security from threats such as horrible weather
2.Can withstand bomb blast performance requirements and hurricane
3.Greater durability in elevated temperatures
4.Fragment retention
5.Thinner and lighter than PVB,about 100 times stronger than PVB
6.SGP film can bond metal plates and membrane,which creats a new filed in aesthetic.


Applications:

1.Explosion-proof glass
2. High-speed train windshield Vitreous stair(it will be stick with the metal)
3.Railings -SGP hurricane glass
4.ceiling
5.Security doors and windows
6. Glass visor
